Three phase four wire digital electricity energy meter is a three phase electricity meter.This electric watt hour meter uses digital technology to measure and record electricity usage. It is usually installed at the end of the power system to measure and record the amount of electricity consumed by users. In general, the Three Phase Four Wire digital kWh meter is an important power measurement equipment that provides accurate power measurement services to power systems and users.
1. Adopt digital sampling technology and SMT technology to improve the measurement accuracy and reliability of products
2. Wide range of measured electricity energy,suitable for power consumption monitoring of different scales.
3. High accuracy,Class 1.0.
4. With fire resistant and better strength,withstand hard and extreme environment.
5. Can add communication:Optical or RS485 or as required communication and related communication protocol
6. With a simple display or multi display modes.(Price is depend on the functions,please talk to us.)
Type | 3 Phase 4 Wire |
Connection | Bottom connected |
Voltage | AC3x220/380V,3x230/400V,3x240/415V.or 120/208V |
Basic current(Ib) | 5A,10A,15A,20A,30A |
Max current(Imax) | 100A |
Starting current | 0.04%Ib |
Frequency | 50Hz,60Hz |
Accuracy | Class 1.0 |
Operating temperature | ~25℃~70℃ |
Display | Digital or Analog type |
Size | short terminal cover: 130.8cm(width)*65.5mm(depth)*180mm(height) long terminal cover: 130.8cm(width)*65.5mm(depth)*215.8mm(height) |
weight | 1kg |
Package | Inner foam box and carton box |
Customized support(OEM) | Yes |
Direct connected
CT connected
| 1. Where is the three phase meter used and installed? |
Three phase four wire electric power meters are widely used in many industries such as industry, commercial buildings, and public facilities |
| 2. If this electric meter can measure the large power consumption devices? |
Yes, Three phase four wire electric energy meter is suitable for measuring high-power equipment. Its application range is usually 10kW and above, which can meet the electricity needs of large-scale residential, commercial and industrial power occasions. |
3. Can i get a sample for trial use first? |
Sure,dear. Please tell us your parameters or we can suggest you some parameters according your device. |
4. Should I get a digital display or analog display? |
There is not so much difference between digital display and analog display. Digital display with LCD screen looks much modern,analog display with register can works better in much colder area. |
