The Single Phase Din Rail Energy Meter with Reset Button is a compact and efficient energy - measuring device designed for single - phase electrical systems. It is specifically designed to be mounted on a DIN rail, which allows for easy installation and integration into various electrical panels. This meter is widely used in residential, commercial, and industrial applications to accurately measure and monitor electrical energy consumption.
It adopts advanced measurement technology to ensure high - accuracy measurement of electrical energy consumption, complying with relevant international standards such as IEC 62053 - 21. It can precisely measure the active energy consumption of single - phase AC power grids at 50Hz or 60Hz.
Equipped with a reset button, which allows users to clear specific energy measurement data as needed, facilitating data management and analysis. For example, it can reset the daily energy display to zero to start a new round of daily energy consumption recording.
With a small volume and light weight, it is suitable for DIN - rail installation, occupying little space in the electrical cabinet. The six - pole width (modulus 12.5mm) complies with the standard JB/T 7121 - 1993.
It has an LCD display that shows clear and intuitive information, including total energy consumption, daily energy consumption, voltage, current, power factor, and other parameters. Some models may also offer backlighting options for easy reading in low - light environments.
It supports various configuration options to meet different application requirements. For example, it can be configured to detect the direction of load current flow automatically, and some models have multiple pulse output ports to facilitate connection with different AMR systems.
Accuracy Class: Usually 1.0, ensuring reliable and accurate measurement.
Rated Voltage: 220 - 240V, suitable for common single - phase power supply voltages.
Rated Current: Options such as 5(30)A, 10(50)A, and 20(100)A are available to meet different load requirements.
It is used to measure the electricity consumption of households, helping residents understand their electricity usage patterns and save electricity.
In commercial buildings and industrial facilities, it is used to monitor and manage the electricity consumption of different departments or equipment, facilitating cost allocation and energy - saving management.
Type | 1 Phase 2Wire |
Connection | Bottom and upside connected |
Voltage | AC220V,230V,240V |
Basic current(Ib) | 5A,10A,15A,20A,30A |
Max current(Imax) | 80A |
Starting current | 0.04%Ib |
Frequency | 50Hz,60Hz |
Accuracy | Class 1.0 |
Operating temperature | ~25℃~70℃ |
Display | Digital type |
Size | 36mm(width)*66mm(depth)*78mm(height) |
weight | 0.2kg |
Package | Inner box and carton box |
Customized support(OEM) | Yes |
|
 |
