EDU02 is a single phase two wire WIFI Tuya digital din rail smart energy meter. This electric wifi smart meter integrated WIFI and Tuya smart technology. It is designed for high level performance, safe and convenient to install.
1. WIFI connection: This electricity smart energy meter supports WIFI connection and can be easily connected to the intelligent network system of the home or industry to realize remote monitoring and control.
2. Tuya Intelligent Smart Technology:This din rail meter communicated by the Tuya intelligent platform, users can easily realize remote management of electric energy meters, including viewing power, setting parameters, etc.
3. Rail installation:The meter intalled on a din rail facilitate quick installation and disassembly in the distribution box or distribution cabinet.
4. High-precision measurement: The electric energy meter has a high-precision measurement function and can accurately record and display electricity data, providing strong support for energy conservation and consumption reduction.
Type | 1 Phase 2Wire |
Connection | Bottom and upside connected |
Volage | AC220V,230V,240V |
Basic current(Ib) | 5A,10A,15A,20A,30A |
Max current(Imax) | 60A |
Starting current | 0.04%Ib |
Frequency | 50Hz,60Hz |
Accuracy | Class 1.0 |
Operating temperature | ~25℃~70℃ |
Display | Digital type |
Size | 36mm(width)*66mm(depth)*100mm(height) |
weight | 0.3kg |
Package | Inner box and carton box |
Customized support(OEM) | Yes |
Communication | Tuya and WIFI |
| 1. How the din rail WIFI smart connect to my mobile? |
First you need to download “Tuya Smart” from app store and register,then add device and connect to the meter.You need to open the bluetooth and WIFI service,more function you will find in the app, above is main function of the device. |
| 2. What is the warranty time of this meter? |
We support 18months warranty. |
3. How to deal with a failure in the WIFI smart meter? |
When wifi smart meter with some issues,please do as below steps:check connections, reset equipment and contact after-sales.first You should check that the device is correctly connected to the power supply and network.If there is no problem with the connection but the device still does not respond, you can try resetting the device.If the problem remains unresolved after resetting the equipment, it is recommended to contact our after-sales service staff.Tepsung will support you all the time. |
